NXP’s Energy Efficient Cortex-M4 MCU with Cortex-M0+ and Advanced Security
Design Files
Receive the full breakdown. See the product footprint and more in the eCad file.
Ultra-Low-Power, Highly Integrated MCU
The K32 L2 MCU family’s low-leakage architecture, combined with its power-optimized peripherals and security features (such as cryptographic acceleration technology, cyclic redundancy check and a true random number generator), make it ideal for consumer, industrial and IoT applications requiring a low-priced, power efficient option with longer battery life.
This family includes a low power Arm® Cortex®-M0+ core and with options scaling from 64 KB to 512 KB Flash and from 32 kB to 128 kB SRAM, the K32 L2 family offers a wide range of memory resources to fit different application tasks within a small-form factor, low power, and highly integrated design.
Product Details
Features
Ultra Low-Power
- Low-power Arm® Cortex®-M0+ core
- Multiple low-power modes enabling the reduction of dynamic power consumption
- Low-power serial peripheral interfaces supporting low-power operation modes without waking up the core
On-Chip Memory
- 64 – 512 KB Flash Memory
- 32 – 128 KB SRAM Memory
- 16 – 32 KB ROM Memory with integrated bootloader
Connectivity and Communications
- USB 2.0 Full Speed integrated with low-voltage regulator
- 4-8 channel DMA for peripheral and memory servicing with reduced CPU loading
- Up to three I2C, up to three LPUART and up to three SPI serial interfaces with DMA support
- FlexIO interface with capability of emulating multiple serial interfaces
- Segment LCD supporting up to 24x8 or 28x4 segments*
Mixed-Signal
- 16-bit ADC module with high accuracy internal voltage reference (Vref)
- Up to two High-speed analog comparator containing a 6-bit DAC for programmable reference input
- One 12-bit DAC
- 1.2/2.1 V internal voltage reference
Timers
- One 6-channel Timer/PWM module-
- Two 2-channel Timer/PWM modules
- Up to two low-power timer
- Up to two Periodic interrupt timer
- Real time clock
Human Machine Interface (HMI)
- Capacitive touch sense interface supporting up to 16 external electrodes**
- GPIO with pin interrupt support
Security**
- Cryptographic acceleration unit supporting acceleration of DES, 3DES, AES, MD5, SHA-1 and SHA-256 algorithms
- Hardware accelerated True Random Number Generator
