Layerscape® 1046A and 1026A Processors
The LS1046A and LS1026A processors integrate quad and dual 64-bit Arm® Cortex®-A72 cores respectively with packet processing acceleration and high-speed peripherals. They are pin-compatible with LS1023A, LS1043A and LS1088A SoC to provide performance scaling for 64-bit Arm, ranging from dual-A53 through octal-A53 to quad-A72 core processors, while maintaining hardware and software compatibility.
Layerscape processors are part of NXP's EdgeVerse™ edge computing platform.
Both devices are proven certifiable to the Arm SystemReady ES standard to ensure interoperability with standard operating systems and hypervisors.
Product Details
Features
Core Complex
- Four Cortex-A72 cores
- 2MB L2 cache
Networking Elements
- 2x 10 GbE, 1x 2.5 GbE, and 5x GbE
- Eight-lane SerDes up to 10 GHz multiplexed across controllers supporting:
- Three PCI Express® Gen 2 interfaces
- SATA 3.0 Interface
Accelerators and Memory Controllers
- DPAA Parse, Classify, and Distribution Engines
- Integrated security engine
- DDR4
Basic Peripherals and Interconnect
- 3x PCIe 3.0 Controllers, x4, x2, x1
- 3x USB 3.0 with integrated PHY
- SATA 3.0 controller
- Quad SPI
Additional Features
- QorIQ® Platform's Trust Architecture
- Arm SMMU for hardware-enhanced virtualization
- FCPBGA 23x23mm
- Pin-compatible with LS1023A, LS1043A, and LS1088A
