NFC TagWriter App by NXP
The NFC TagWriter app by NXP allows writing tags, enabling users to store contacts, bookmarks, pair with Wi-Fi, or Bluetooth®, enable hotspots, send text messages and much more all with just a tap. Once data has been stored the application allows also reading and viewing the programmed data including options to launch applications automatically based on the contained data.
Software Details
Features
- The NFC TagWriter by NXP supports a series of configuration options adapting the application to your own needs and preferences. The application fully supports the NFC Forum Type Tag portfolio. This includes a whole range of NXP NFC-enabled contactless IC products like MIFARE Ultralight, MIFARE DESFire, NTAG 21x, NTAG 42x, ICODE & many others. TagWriter supports any NDEF pre-formatted tags for all NDEF operations but formatting to NDEF feature is limited only to NXP Tags.
- Easily create tag content from your contacts and bookmarks
- Create new content with the included NFC data set editor
- WiFi Pairing for handsets supporting this feature
- Bluetooth pairing for all NFC enabled Android versions
- Application launching with optional data handover
- Convert QR Codes into NFC data sets
- View the existing contents of a tag
- Export, import and share NFC data sets
- Manage your own history of tags viewed and written
- Tap to Launch feature to execute content of NFC tags with a simple tap
- Backup the contents of a tag before writing it
- Erase the contents of a tag
- Insert increasing counter values when writing NFC data sets
- Write-protect a tag
- Write multiple tags in sequence
- Write multiple Datasets in CSV format on multiple tags in sequence
Supported Devices
- MIFARE_DESFIRE_LIGHT: MIFARE® DESFire® Light
- MFPEV2: MIFARE Plus® EV2: Secure IC for Contactless Smart City Services
- MF1S50YYX_V1: MIFARE Classic® EV1 1K - 4K
- MF0ULX1: MIFARE Ultralight® EV1
- NTAG424DNA: NTAG® 424 DNA / 424 DNA TagTamper – Advanced Security and Privacy for Trusted IoT Applications
- NTAG_223_224_DNA: NTAG® 223 / 224 DNA - Certified NFC Security Chip Technology to Enable Trusted IoT Applications at Scale
- NTAG213_215_216: NTAG® 213/215/216: NFC Forum Type 2 Tag Compliant IC with 144/504/888 Bytes User Memory
- ICODE-3: ICODE 3: High-performance HF tag IC for IOT
- SL2S6002FUD: ICODE DNA NFC Forum Type 5 Tag with AES Cryptography
- SL2S2602: ICODE® SLIX2 NFC Forum Type 5 Tag with Originality Signature
- SL2S2002_SL2S2102: ICODE® SLIX
- SL2S5002_SL2S5102: ICODE® SLIX-L
Downloads
Quick reference to our software types.
3 downloads
-
Debugging and Visualization Tools
TagWriter Android App APKupdated
-
Software Development Resources
NFC TagWriter by NXP - Apple Store
-
Software Development Resources
NFC TagWriter by NXP - Google Play
Note: For better experience, software downloads are recommended on desktop.
