ColdFire MCF5225X Connectivity Tower System Module

TWR-MCF5225X Active

Roll over image to zoom in

The TWR-MCF5225X module is a development board for the NXP® MCF5225X V2 ColdFire® Connectivity MCUs, which are ideal for factory automation, building control and medical applications.

  • Designed to enable rapid prototyping and development for applications requiring connectivity through Ethernet, USB and CAN.
  • The TWR-MCF5225X operates as a standalone debug tool and can also be combined and used as part of the modular Tower® System development platform

Product Details

Supported Devices

Processors and Microcontrollers

ColdFire® V2 MCUs

  • MCF5225X: One-Stop-Shop Connectivity 32-Bit Microcontrollers

Features

Microcontroller

  • Complimentary MQX™ software solutions
  • Connectivity: USB 2.0 full-speed host/device/OTG controller; FlexCAN controller; 10/100 Ethernet controller
  • External Mini-FlexBus interface
  • Cryptographic accelerator unit
  • Integrated, open source BDM
  • Small form factor (59 mm x 90 mm) standard with Tower® System

Buy Options

TWR-MCF5225X-Image

Click to expand

  • TWR-MCF5225X
    Active

  • Tower System, ColdFire MCU Module, MCF5225X, Connectivity USB 2.0, FlexCAN, 10/100 Ethernet.

    • Part Number TWR-MCF5225X contains:
      • TWR-MCF5225X board with a MCF52259 32-bit MCU
      • Necessary cables
      • DVD with lab tutorials, software, training and collateral
      • Quick Start Guide document
    • Part Number TWR-MCF5225X-KIT also contains:
      • TWR-SER - Tower System Serial Module
      • TWR-ELEV - Tower System Elevator Modules
  • For a quantity of 1
