Front View Camera
Camera systems in advanced driver assistance systems can analyze the video content for lane departure warning (LDW), automatic lane keeping assist (LKA), high/low beam headlight control and traffic sign recognition (TSR).
For a front view camera, an image sensor provides incoming video frames to a dual-core MCU optimized with DSP extensions for image processing. Additional system requirements include an appropriate physical communication interface, a power supply, an optional DRAM and embedded flash for low system cost.
Application Details
Block Diagram
Recommended Products for:
Front View Camera
Select a block to see our recommended products.
MCU
Automotive Ethernet
- SJA1110: Multi-Gig Safe and Secure TSN Ethernet Switch with Integrated 100BASE-T1 PHYs
- TJA1103: TJA1103, ASIL B Compliant Automotive Ethernet 100BASE-T1 PHY Transceiver
- TJA1120: TJA1120, ASIL B Compliant Automotive Ethernet 1000BASE-T1 PHY Transceiver
- SJA1105TEL: Five- Ports AVB and TSN Automotive Ethernet Switch
- TJA1101: TJA1101B, IEEE 100BASE-T1 Compliant Automotive Ethernet PHY Transceiver
Power Management IC
- FS84: Safety System Basis Chip for S32 Microcontrollers, Fit for ASIL B
- FS5600: Automotive Dual Buck Regulator and Controller with Voltage Monitors and Watchdog Timer
- PF7100: 7-Channel Power Management Integrated Circuit for High Performance Applications, Fit for ASIL B Safety Level
- PF5024: Multi-Channel (4) PMIC for Automotive Applications – 4 High Power, Fit for ASIL B Safety Level
Automotive Ethernet
- SJA1105TEL: Five- Ports AVB and TSN Automotive Ethernet Switch
- TJA1101: TJA1101B, IEEE 100BASE-T1 Compliant Automotive Ethernet PHY Transceiver
